Apply to all tire position of dumper and light truck which travels short distance within 100km and low speed on extremely bad road conditions, especially for overloading.
Size |
Ply Rating | Std | Load Index | Speed Rating | Max load | Max | Tread | |
Inch | Single/Dual | Single | Dual | kPa | mm | |||
7.50R16 | 14 | 6G | 122/118 | K | 1500 | 1320 | 770 | 16.5 |
8.25R16 | 14 | 6.5H | 126/122 | K | 1700 | 1500 | 670 | 18 |
8.25R16 | 16 | 6.5H | 128/124 | K | 1800 | 1600 | 770 | 18 |
8.25R20 | 14 | 6.5 | 136/134 | E | 2240 | 2120 | 830 | 19.5 |
8.25R20 | 16 | 6.5 | 139/137 | D | 2430 | 2300 | 930 | 19.5 |
9.00R20 | 16 | 7 | 144/142 | D | 2800 | 2650 | 900 | 20.5 |
10.00R20 | 18 | 7.5 | 149/146 | D | 3250 | 3000 | 930 | 23.5 |
11.00R20 | 18 | 8 | 152/149 | D | 3550 | 3250 | 930 | 24.5 |
12.00R20 | 18 | 8.5 | 154/151 | E | 3750 | 3450 | 830 | 24.5 |
