Apply to all tire position of dumper and light truck which travels short distance within 100km and low speed on extremely bad road conditions, especially for overloading
Size |
Ply | Std | Load |
Speed Rating | Max load | Max | Tread | |
Inch | Single | Single | Dual | kPa | mm | |||
9.00R20 | 16 | 7 | 144/142 | K | 2800 | 2650 | 900 | 21.5 |
10.00R20 | 18 | 7.5 | 149/146 | G | 3250 | 3000 | 930 | 23.5 |
11.00R20 | 18 | 8 | 152/149 | G | 3550 | 3250 | 930 | 24.5 |
12.00R20 | 18 | 8.5 | 154/151 | E | 3750 | 3450 | 830 | 24.5 |
14.00R25 | *** | 10.00/1.5 | 169 | B | 5800 | – | 700 | 29 |
